Product Information
- 5 MHz Bandwidth: The oscilloscope's real-time sampling rate is up to 20MS / s and the analog bandwidth is 5MHz. Aperiodic digital signaling can be used freely.
- Storage and Deletion Function: It is with 16M storage space, and very convenient and fast to store waveform. Support for thumbnail browsing, detailed information viewing, page turning, delete waveform functions etc..
- 2.4 Inch Color Display: A high-definition LCD screen with 2.4-inch 320 * 240 resolution. It also support day mode and night mode display. And when Waveform refresh, the screen doesn't flash.
- Portable: The Mini oscilloscope is built-in 1200mAh rechargeable lithium battery, it can be used continuously for 3 hours when fully charged. Equipped with an efficient one-button, the measurement waveform can be displayed without complicated adjustments.
- High measurement voltage range: 1X can measure 0~40 V, 10X can measure 40~800V. Up to 11 parameters measured: VPP Vmax, Vmin, Vavg, Vrms frequent, Duty +, Duty-, Time +, Time-, Time.
