Product Information
- Total magnification: 40X-100X-250X-400X-1000X-2500X; Eyepieces: widefield WF10X and WF25X; Objectives: achromatic DIN 4X, 10X, 40X(S), 100X(S, Oil); Viewing head: 45 degrees inclined 360 degrees swiveling digital binocular head; Sliding adjustable interpupillary distance: 2-3/16inch ~ 2-15/16inch(55~75mm); Ocular diopter adjustable on both eyetubes
- Total magnification: 40X-100X-250X-400X-1000X-2500X; Eyepieces: widefield WF10X and WF25X; Objectives: achromatic DIN 4X, 10X, 40X(S), 100X(S, Oil); Viewing head: 45 degrees inclined 360 degrees swiveling digital binocular head; Sliding adjustable interpupillary distance: 2-3/16inch ~ 2-15/16inch(55~75mm); Ocular diopter adjustable on both eyetubes
- Total magnification: 40X-100X-250X-400X-1000X-2500X; Eyepieces: widefield WF10X and WF25X; Objectives: achromatic DIN 4X, 10X, 40X(S), 100X(S, Oil); Viewing head: 45 degrees inclined 360 degrees swiveling digital binocular head; Sliding adjustable interpupillary distance: 2-3/16inch ~ 2-15/16inch(55~75mm); Ocular diopter adjustable on both eyetubes
- Nosepiece: revolving quadruple; Stage: double layer X-Y mechanical stage with scales, size: 4-1/2inchx 4-15/16inch (115mm x 125mm); Stage X-Y stroke (travel range): 2-13/16inch x 1-3/16inch (70mm x 30mm); Condenser and diaphragm: NA1.25 Abbe condenser with iris diaphragm and filter holder,rack and pinion adjustment; Transmitted (lower) illuminator: replaceable LED light, intensity adjustable
- Focus: coaxial coarse and fine knobs on both sides; Stage upward moving lock protects objectives and slides; All metal mechannical components; Power supply: AC/DC adapter, 100-240V
- Built-in digital camera: - Imaging device: 1.3 mega pixels, 1/2.5inch CMOS - Effective pixels: 1280x1024 - Maximum still image resolution: 1280x1024 pixels - Frame rate: 6 frames per second at 1280x1024, 10 frames per second at 1024x768 - Interface: USB2.0 ( 480MB/second) - SNR: >40dB - Software compatible with Windows and Mac OS X (Photo Booth)
- 5-year warranty against manufacturing defects
