Product Description
How to Use:
The instrument socket can be connected to the interface of the controller. If you need to connect other accessories, please follow the instructions.
Instrument line color definition:
1.Red wire: positive power supply
2.Yellow wire: electric door lock
3.Blue wire: signal sending
4.Green wire: signal receiving
5.Black wire: negative power supply
6.Brown wire: light positive
7.White wire: lights negative
Specification:
Item Type: 350W Brushless Motor Controller Kit
Weight: Approx.510g / 18.0oz
Material: Aluminum Alloy
Controller Box Size: Approx.9 x 5.3 x 3cm / 3.5 x 2.1 x 1.2in
Voltage: DC48V, 60V Universal
Power: 350W
Current Limiting: 13A
Low Voltage: DC42V, 53V
Package List:
1 x Controller
1 x Meter
1 x Manual
The instrument socket can be connected to the interface of the controller. If you need to connect other accessories, please follow the instructions.
Instrument line color definition:
1.Red wire: positive power supply
2.Yellow wire: electric door lock
3.Blue wire: signal sending
4.Green wire: signal receiving
5.Black wire: negative power supply
6.Brown wire: light positive
7.White wire: lights negative
Specification:
Item Type: 350W Brushless Motor Controller Kit
Weight: Approx.510g / 18.0oz
Material: Aluminum Alloy
Controller Box Size: Approx.9 x 5.3 x 3cm / 3.5 x 2.1 x 1.2in
Voltage: DC48V, 60V Universal
Power: 350W
Current Limiting: 13A
Low Voltage: DC42V, 53V
Package List:
1 x Controller
1 x Meter
1 x Manual
Product Information
- Manufacturing Material --- The controller housing is made of high quality metal material, groove design, with good heat dissipation function, can protect the internal circuit, so as to avoid thermal overload.
- Stable Speed and Sensitive Control --- Brushless motor controllers provide steady speed and sensitive control of braking and directional changes.
- Instrument Display Contents --- Single running mileage and running time, real time speed, battery power and voltage, gear indication cumulative average speed, total mileage, cumulative maximum speed, cruising indication, 6km/h boost and indication, real time running power, real time running current, fault icon code, etc.
- Handle Diameter --- Mounted in the middle of handlebars, handle diameter range are 22.2mm / 0.9in, 25.4mm / 1.0in, 28.6mm / 1.1in adapter ring.
- Easy to Use --- Easy to use and fine workmanship. Without any difficult requirements even though you use it for the first time.
