Product Information
- INCLUDES: (1) Power Tool Paddle Switch (GANG BOX NOT INCLUDED)
- FUNCTION: Performs as an emergency power off safety switch box designed to safeguard your metal and woodworking machines
- FEATURES: Large color coded emergency STOP paddle for visibility, labeled and easy-to-install wiring, PLUS a convenient design that fits deep gang boxes or standard boxes with an extension ring (6-32 hardware not included)
- VERSATILE: Works with a wide assortment of popular name brand table saws, router tables, bandsaws and other power tools
- RATED: Single phase, Dual voltage 110/220 volt smart switch, 2 HP/35 amps at 120 volts; 3 HP/20 amps at 230 volts | Approved according to UL508 E195428 (Please Note: The switch is built with heavy duty electrical components and a force range of 40-60 Newtons or 9 to 13.5 pounds-force is required to activate)
- Please note: The switch plate is attached to the switch with M4 hardware. 6-32 hardware (screw and nut) will be required for some installations.
