Product Information
- Measuring Range: -25 to +25 mm.W.C ; Accuracy: +/-0.5% of Full Scale
- Display: Integrated 4 Digit Red LED 7 Segment Display 0.8”; Sensor: Integrated High Speed Differential Pressure Sensor
- Medium: Air or Gases ( Non Corrosive ); Maximum Over Pressure: 2 Times the rated pressure; Power: 24 Volts D.C. Typical
- Alarms: Built In High & Low Buzzer Alarm for Process Set Parameter Violation with Acknowledgement Key; Unit Selection: Factory Fixed Selection for mm.W.C/Pascals
- Connection: 2 Nos. Hose Nipples of 4mm. Stainless Steel at the Back; Size: Instrument Enclosure is in 100×90×30 mm. (W×H×D); Construction : M.S. Powder Coated Body with Stainless Steel Front Flush Plate for Modular Wall Fitment in Clean Rooms
